Crown XLS1502, 2-Channel Power Amplifier – 525W
The Crown XLS 1502 Stereo Power Amplifier offers 525W at 4 Ohm in a lightweight chassis using the company’s ultra-efficient DriveCore Class D amplification platform. The amplifier includes built-in DSP with a dedicated band pass filter per channel, an integrated PureBand Crossover System, and Peakx Limiters to provide maximum output while protecting your speakers.
.iframe-container{
position: relative;
width: 100%;
padding-bottom: 56.25%;
height: 0;
}
.iframe-container iframe{
position: absolute;
top:0;
left: 0;
width: 100%;
height: 100%;
}
For inputs, the rear panel includes a pair of XLR-3F connectors, 1/4″ and RCA inputs for flexible connections with a selectable input sensitivity of either 1.4 Vrms or 0.775 Vrms. Outputs are provided on both speakON and binding post connectors.
You can set the amplifier’s sleep mode for a designated period of time without having to press a button, as well as turn off all LED indicators except for clip and thermal to reduce distractions in dark venues. A security mode can be engaged to disable menu buttons, which can be locked and unlocked by entering a combination code. Full system reset allows for factory settings to be restored and a remote power trigger allows you to turn the unit on and off.
Product Specifications:
Number of Channels: 2
Amplifier Power Rating:
2 Ohms:
775 W per Channel
4 Ohms:
525 W per Channel
1550 W Bridged
8 Ohms:
300 W per Channel
1050 W Bridged
Amplifier Class: Class-D
Load Impedance / Voltage:
Bridged: 4 Ohms
Performance:
Protections: Overload, Thermal
Frequency Response: 20 Hz to 20 kHz +0/-1 dB (at 1 W)
Damping Factor: > 200
Input Sensitivity: 1.4 Vrms
SNR: > 103 dB
THD: < 0.5%
Intermodulation Distortion: < 0.3%
Crosstalk:
> 85 dB (1 kHz)
> 55 dB (20 kHz)
Signal Processing:
DSP: Yes
Crossover: 24 dB/Octave Linkwitz-Riley
EQ: No
Filters:
Low-Pass, 24 dB/Octave Linkwitz-Riley
High-Pass, 24 dB/Octave Linkwitz-Riley
Notch/Band-Pass, 24 dB/Octave Linkwitz-Riley
Limiting: Yes
Connectivity:
Analog Audio I/O:
2x XLR Input
1x 2RCA Input
2x 1/4″” Thru
2x Binding Post Pair Output
2x speakON NL4 Output
Power:
AC Input Power: 100 to 240 VAC, 50 / 60 Hz
AC Power Connector: IEC
Power Consumption: 425 W
Physical:
Display & Indicators: LCD (Backlit/Stereo Mode)
Rackmount Size: 1 U
Cooling: Fan
Product Weight: 8.6 lbs. / 3.9 kg
Product Dimensions: 19.0 x 7.7 x 3.5 Inches
Shipping Weight: 11.6 lbs.
Shipping Dimensions (LxWxH): 21 x 12 x 6 Inches
