Description
B-Stock: Shure BLX188/CVL-H9 Wireless Dual Presenter System with Two CVL Lavalier Microphones – H9 (512-542 MHz)
The Shure BLX188/CVL-H9 Wireless Dual Presenter System with Two CVL Lavalier Microphones – H9 (512-542 MHz) combines professional-quality sound with simple setup and up to 14 hours battery life for great audio performance for two presenters right out of the box. The system includes BLX88 tabletop dual-channel receiver, 2 CVL lavalier microphones with BLX1 bodypack transmitters, lavalier clips, power supply, 2 sets of AA batteries, windscreens and user guide.
Superior Audio – Perform with Confidence
Get the show going with no wires attached. Professional Shure sound for every band and any vocal need.
Reliable Signal – Extend Your Range
With a range of up to 300 feet (100m), you can take the show into the crowd without interruption.
Easy Setup – Own the Stage
BLX will have you up and running in record time with one-touch scan and selection.
Battery Life – 14 Hours of Power
Because BLX transmitters get up to 14 hours of power from a single pair of AA batteries, the show can go on and on (and on).
Systems Expansions – Run Up To 12 Channels Per Frequency Band
You’ll probably need to find a bigger stage before you run out of channels.
Versatility Included – You’ve Got Options
An impressive variety of Shure microphones are available in BLX systems, so you can find what works for you.
In the Box
1 PS24 Power Supply
2 windscreens
2 lavalier clips
B-stock units may have minor cosmetic scratches or dents. Some product accessories or the original packaging may be missing when received. B-Stock units are not covered by a full manufacturer warranty. Please call us for details.
Product Specifications:
Wireless Technology: Analog UHF
Number of RF Channel Frequencies: 123
Included Transmitters: 2x Bodypack
Diversity: Antenna Diversity
RF Frequency Band: H9: 512 to 542 MHz
RF Bandwidth: 24 MHz
RF Channel Scanning: Auto-Scan
Max Operating Range: 300′ / 91.4 m (Line of Sight)
Max Transmitters per Band: 12
Built-In Recorder: No
Timecode Support: No
Mobile App Compatible: No
Dynamic Range: 100 dBA
Receiver:
Receiver Type: Tabletop
Antenna: 2x Internal, Fixed
Number of Audio Channels: 2
Audio I/O:
2x XLR 3-Pin Male Balanced Output
2x 1/4″” TRS Female Unbalanced Output
Audio Output Level:
XLR Outputs:
-27 dBV (Mic Level)
1/4″” Outputs:
-13 dBV (Instrument Level)
Frequency Response: 50 Hz to 15 kHz (Dependent on Mic)
Impedance:
XLR Outputs:
200 Ohms
1/4″” Outputs:
50 Ohms
Adjacent Channel Isolation: >50 dB
Power Requirements: AC/DC Power Adapter
AC/DC Power Adapter: 12 to 15 VDC at 160 mA, Center-Positive (Included)
Input Power: 100 to 240 VAC, 50 / 60 Hz at 150 mA
DC Input Power: 12 to 15 VDC at 160mA
Display & Indicators:
2x Multi-Segment LED (Channel, Group)
4x LED (AF Level, Sync)
Housing: ABS
Operating Temperature: 0 to 135°F / -17 to 57°C
Dimensions: 15.3 x 1.6 x 4.6″ / 388 x 40 x 116 mm
Weight: 15.1 oz / 429 g
Transmitter Type: Bodypack
RF Output Power: 10 mW
Audio I/O: 1x TA4/Mini-XLR 4-Pin Male Input (Locking)
Muting: Off/On Switch
Auto-Level Control: No
Gain Range: -16 to +10 dB
Sync Method: Manual
Antenna: 1x Flexible Whip, Fixed (Belt pack)
Power Requirements: Battery
Battery Type: 2x AA (Included)
Approx. Battery Life: 14 Hours (Alkaline)
Display & Indicators:
1x Multi-Segment LED (Channel, Group)
1x LED (Battery Status, Power)
Housing: ABS
Dimensions: 2.5 x 4.3 x 0.8″ / 64 x 110 x 21 mm
Weight: 2.6 oz / 75 g (without Batteries)
Microphone Type: Lavalier
Sound Field: Mono
Capsule: Electret Condenser
Polar Pattern: Cardioid
Frequency Range: 50 Hz to 20 kHz
SNR: 72 dB
Equivalent Noise Level: 22 dB A-Weighted
Maximum SPL: 139 dB SPL
Impedance: 600 Ohms
Dynamic Range: 117 dB
Output Connector: 1x TA4F/Mini-XLR 4-Pin Female Unbalanced (Locking)
Cable Length: 4.27′ / 1.3 m
Operating Voltage: 5 V
Weight: 0.88 oz / 25 g
Shipping Weight: 4.4 lbs
Shipping Dimensions (LxWxH): 19.2 x 16.2 x 3.4″
